Plastic Dryer, Dehumidifier, Dehumidifying Dryer, Industrial Dehumidifier, Industrial Dryer, Dry Air Dryer, Hot Air Dryer, Drying Machine
ODD-xxx/xxxH
① ② ③
① Orste Dehumidifying Dryer
② Hopper Capacity (L)
③ Dehumidifying Air Quantity (m3/hr), H: Honeycomb
1. The ODD dehumidifying dryers use honeycomb dehumidifiers with an elegant semi-integral appearance.
2. Combines the two functions of dehumidifying and drying into one machine, occupy little space which ensures the whole arrange of the workshop.
3. Insulated drying hopper features dry air down-blowing and cyclone exhaust design. This improves drying efficiency and reduces energy consumption while maintaining a steady drying effect.
4. Compact in size for ease of movement.
5. Microprocessor is standard equipment, ensures convenient operation.
The sealed honeycomb rotor is divided into dehumidifying, regenerative and cooling zones in the rotary dehumidifier. Damp and hot air from dry material hopper is blown into rotor after cooled. Moisture from the air is absorbed by rotor and is then absorbed by regeneration heating air. Two strands of airflow function on the rotor. And with the rotation of the rotor, moisture from the air is absorbed and expelled after absorbed regeneration air to form stable low dew-point air, which is dries to the drying temperature and then is blown into drying hopper to closed circle to dry material.
| Model ODD- | Regen. Heater (kw) | Regen. Blower (kw) | Drying Heater (kw) | Drying Blower (kw) | Dry Air Volume (m3/hr) | Insulated Hopper (L) | Dimension H*W*D (mm) | Weight (kg) |
| 20/40H | 4 | 0.2 | 4 | 0.12 | 40 | 20 | 1260*960*860 | 150 |
| 40/40H | 4 | 0.2 | 4 | 0.12 | 40 | 40 | 1260*960*860 | 165 |
| 80/40H | 4 | 0.2 | 4 | 0.12 | 40 | 80 | 1650*1060*860 | 190 |
| 120/80H | 3 | 0.2 | 6 | 0.75 | 80 | 120 | 1780*1220*855 | 250 |
| 160/80H | 3 | 0.2 | 6 | 0.75 | 80 | 160 | 1740*1220*855 | 255 |
| 160/120H | 3 | 0.2 | 6 | 0.75 | 120 | 160 | 1740*1220*855 | 265 |
| 230/120H | 3 | 0.2 | 6 | 0.75 | 120 | 230 | 2010*1220*855 | 295 |
| 300/200H | 4 | 0.4 | 12 | 1.5 | 200 | 300 | 2040*1450*1050 | 420 |
| 450/200H | 4 | 0.4 | 12 | 1.5 | 200 | 450 | 2040*1450*1050 | 550 |
| 600/400H | 7.2 | 0.75 | 18 | 3.75 | 400 | 600 | 2380*1745*1255 | 620 |
| 750/400H | 7.2 | 0.75 | 18 | 3.75 | 400 | 750 | 2610*1745*1255 | 650 |
| 900/700H | 10 | 1.5 | 24 | 5.5 | 700 | 900 | 2640*2140*1380 | 830 |
| 1200/700H | 10 | 1.5 | 24 | 5.5 | 700 | 1200 | 3070*2140*1380 | 870 |
Company Products Advantages
With many years of experience and accumulation in scientific researching and designing of our five series products: Dehumidifying and Drying, Feeding and Conveying, Dosing and Mixing, Heating and Cooling, Granulating and Recycling, and upholding the principle of “Focusing on Product Details, Pursuing Excellent Quality”, “Perfect Product Comes From Endless Innovation”.
ORSTE spares no efforts to innovate its technology while improving product quality, and now it is an industry leader with its mature technology, professional research and development ability, quick marketing capability and qualified site construction team in peripheral equipment of plastic molding.
Company’s Main Products
ORSTE’s large scale Central Material Conveying System and cooling water circulation system including three major systems of centralized raw material drying, water temperature control and metering & mixing, are extensively applied in plastic injection molding industry.
The main products of the company are a series of high-tech products including Desiccant Honeycomb Dehumidifiers, Hopper Dryers, “Three-in-one” Compact Dryers, Auto / Semi-auto Weighing & Packing Machine (for plastic 25kg packages), Auto-loaders, Mold Temperature Controllers, Industrial Chillers, Mixers and Blenders, Masterbatch Dosers, Granulators, and Vibrating Screens.
